Hirschmann Single Display Conductivity Transmitter

Hirschmann Single Display Online Conductivity Transmitter The DDG Series Industrial Online Conductivity Transmitters include this Hirschmann single display online conductivity transmitter. The unit features a Hirschmann connector with LED digital display. The LED display shows conductivity values in real time. Background light allows clear reading in dark environments. The power supply is DC24V. Accuracy is Class 1.5 or Class 2.5. Temperature compensation uses PT1000 sensor. PT100 and 10k ohm options are available on request. The unit accepts various electrode types including 0.01 constant 0.1 constant 1.0 constant and inductive probe. The transmitter supports standard signal outputs. Isolated 4-20mA output is available for long distance transmission. RS485 digital output is also available for bus networking. Extended cables are available for remote mounting. The rod material can be PPR stainless steel or other materials upon request. Multiple installation types are available includin…
