Atv Utility Electric Winch 3500 Lbs

Atv Utility Electric Winch 3500 Lbs Electric UTV Winch 3500lb Item No.EWT3500A Features:1. Free steel reducer gear2. Patent clutch structure3. Free spooling clutch4. Automatic screw cone braking action5. DC 12V or DC 24V Power drive optional6. High crrunt working switch control directly7. ATV handlebar switch control EWT3500 SPECIFICATION   Rated line pull 3500 lbs (1588 kgs) Motor: permanent magnet 12V:Input: 2.0kW / 2.7hp; Output: 0.9 kW / 1.2hp 24V:Input: 2.4kW / 3.2hp; Output: 1.0 kW / 1.3hp   Gear reduction ratio 166:1 Cable (Dia.× L) Ø 7/32″×44.0′ (Ø5.4mm×13.4m) Drum size (Dia.× L) Ø 2.0″×3.2″ (Ø50.4mm×82 mm) Mounting bolt pattern 3.13″ (79.5 mm) 2-M8 Pull Speed Amperes Volts First layer Line Pull And Rope Capacity In Layer Line Pull Ibs (kgs) Line Speed Ft/min (m/min) Current A Layer of cable Rated line pull lbs(kgs) Total Rope On Drum ft (m)   12V DC 24V DC 12V DC 24V DC 1 3500(1588) 8.5(2.6) 0 14.4(4.4) 14.4(4.4) 28 14 2 2932(1331) 18.7(5.7)…

Heavy Duty Winch 2 Speed Electric Winch Side By Side Winch Recovery Winch 4x4 Winch
