DC Contactor ALBRIGHT HV500AF-23

DC Contactor ALBRIGHT HV500AF-23 for Electric Energy 12V-1000VProduct Detail Reference                                          Modle Paramenter name HV500AF-23 Rated Contact Voltage 12V-1000V D.C. Continuous Operating Current 250A (50mm? or 1-1/0 AWG cables)  Continuous Operating Current (Max) 500A (190mmor350 MCM busbars) Coil Voltage Range 12V D.C.-96V D.C Contact Arrangement: Main SPST-NO Auxiliary: SPST-NOSPST-NCSPST-NC Mirror Voltage Drop Typically <30mV at 100A Insulation Resistance >200MQ Dielectric Withstand Test (at SeaLevel): 4000V D.C.Leakage <1mA Maximum Altitude 3000m Environmental Seal Contacts, Auxiliary and PWM CircuitHemetically Sealed -Exceeds lP67 Weight: Switch:400 gms Bracket:20 gms Connection Wire Length: Coil:250mm Auxiliary:280mm Shock, 1/2 Sine, 11ms (G): Closed:20G Peak Open:20G Peak Vibration, S…
