C31A7 TINY Built In Type LED Driver

1.Product feature Product feature Current ripple: ±5% Protection: open circuit / short circuit / overload / class II Start time:≤0.5S(230VAC，full load) Ambient Temp: -20~60℃ Storage Temp: -25~85℃ 5 years warranty Certificates: TUV/CE/SAA/CB/CCC Application: Wall lamp，Downlight，Ceiling light Size:  8-14W:  Ф42*22mm (R*H)  2.Product parameter list 3.Connected quantities of different current Breaker 4.Lifetime curve 5.Wiring Diagram 6.Packing information 7.Wiring instructions • All connections must be kept as short as possible to ensure good EMI performance for compact led driver and compact round Led Driver.   • Mains leads should be kept apart from the LED driver and other cables (ideally 5–10 cm distance).   • It is recommended that the maximum length of output wires is 3 m.   • Secondary switching is not permitted, except for Constant Voltage models.   • Incorrect wiring can damage LED modules and the compact led driver.   • The wiring must be protected against shor…
