ANSI Standard Centrifugal Transfer Chemical Pump

JHBB/JHBD pump is a two-stage, radially split, two-end supported centrifugal pump, complying with API610-11th standard. JHBB is first stage single suction type, and JHBD is first stage double suction type. The dimensions of the inlet and outlet flanges meet ANSI or ISO standards. The design of the sealing chamber complies with the ISO21049/API682 sealing standard and is suitable for installing cartridge type single seals, pressure string seals, or non-pressure string seals. The connections of flushing, cooling, heating, quenching, and buer pipelines comply with the API plan. （Diameter）：50 ～ 300mm （Flow）：～ 2000m³/h （Head）：～ 740m （Pressure）: ～ 10MPa （Temperature）: -29℃～ 425℃    Suitable for transporting light hydrocarbon media, corrosive media, high-temperature media, such as atmospheric distillation, alkylation, vacuum distillation, delayed coking, liquefied natural gas and other devices. Applied in industries such as refineries, petrochemicals, crude oil…
